PRODUCT
>>
Gas Discharge
SERIES SURGE PROTECTOR(SURGE ARRESTER)
﹛
Item Name:
Gas Discharge Protector
Insertion loss:
≒
0.20
Model:
BLQ-GD-3GNBS
V.S.W.R:
≒ 1.15
Class:
Gas Discharge
Impedance:
50 次
Frequency:
DC-3000MHz
Bulkhead:
Yes
Peak Power:
200
W (MAX)
Connector:
N-M/F
Discharge Capacity:
20KA
Temperature:
-40
⊥
- +
85
⊥
Item Name:
Gas Discharge Protector
Insertion loss:
≒
0.20
Model:
BLQ-GD-3GNBD
V.S.W.R:
≒ 1.15
Class:
Gas Discharge
Impedance:
50 次
Frequency:
DC-3000MHz
Bulkhead:
Yes
Peak Power:
200
W (MAX)
Connector:
N-F/F
Discharge Capacity:
20KA
Temperature:
-40
⊥
- +
85
⊥
Item Name:
Gas Discharge Protector
Insertion loss:
≒
0.20
Model:
BLQ-GD-3GNBR
V.S.W.R:
≒ 1.15
Class:
Gas Discharge
Impedance:
50 次
Frequency:
DC-3000MHz
Bulkhead:
Yes
Peak Power:
200
W (MAX)
Connector:
N-M/F
Discharge Capacity:
20
Temperature:
-40
⊥
- +
85
⊥
Item Name:
Gas Discharge Protector
Insertion loss:
≒
0.20
Model:
BLQ-GD-3GNBR
V.S.W.R:
≒ 1.15
Class:
Gas Discharge
Impedance:
50 次
Frequency:
DC-3000MHz
Bulkhead:
Yes
Peak Power:
200
W (MAX)
Connector:
N-F/F
Discharge Capacity:
20
Temperature:
-40
⊥
- +
85
⊥
Item Name:
Gas Discharge Protector
Insertion loss:
≒
0.20
Model:
BLQ-GD-6GNBR
V.S.W.R:
≒ 1.40
Class:
Gas Discharge
Impedance:
50 次
Frequency:
DC-6000MHz
Bulkhead:
Yes
Peak Power:
200
W (MAX)
Connector:
N-M/F
Discharge Capacity:
10KA/20KA
Temperature:
-40
⊥
- +
85
⊥
Item Name:
Gas Discharge Protector
Insertion loss:
≒
0.20
Model:
BLQ-GD-6GNFBR
V.S.W.R:
≒ 1.40
Class:
Gas Discharge
Impedance:
50 次
Frequency:
DC-6000MHz
Bulkhead:
Yes
Peak Power:
200
W (MAX)
Connector:
N-F/F
Discharge Capacity:
10KA/20KA
Temperature:
-40
⊥
- +
85
⊥
Item Name:
Gas Discharge Protector
Insertion loss:
≒
0.10
Model:
BLQ-GDBK-1GNFFBS
V.S.W.R:
≒ 1.10
Class:
Gas Discharge
Impedance:
50 次
Frequency:
DC-1GHz(DC Block)
Bulkhead:
Yes
Peak Power:
375
W (MAX)
Connector:
N-F/F
Discharge Capacity:
10KA/20KA
Temperature:
-40
⊥
- +
85
⊥
Item Name:
Gas Discharge Protector
Insertion loss:
≒
0.30
Model:
BLQ-GDI-6G43MD/MF
V.S.W.R:
≒ 1.20
Class:
Gas Discharge Inside
Impedance:
50 次
Frequency:
DC-6G
Operating Vtg:
75V
Peak Power:
500
W (MAX)
Connector:
4.3-10-M/F
Discharge Capacity:
5KA(10KA MAX)
Temperature:
-40
⊥
- +
70
⊥
Item Name:
Gas Discharge Protector
Insertion loss:
≒
0.30
Model:
BLQ-GDI-6G43MD/FF
V.S.W.R:
≒ 1.20
Class:
Gas Discharge Inside
Impedance:
50 次
Frequency:
DC-6G
Operating Vtg:
75V
Peak Power:
500
W (MAX)
Connector:
4.3-10-F/F
Discharge Capacity:
5KA(10KA MAX)
Temperature:
-40
⊥
- +
70
⊥
Item Name:
Gas Discharge Protector
Insertion loss:
≒
0.30
Model:
BLQ-GD-3G43MD/MF
V.S.W.R:
≒ 1.20
Class:
Gas Discharge
Impedance:
50 次
Frequency:
DC-3G
Operating Vtg:
75V
Peak Power:
500
W (MAX)
Connector:
4.3-10-M/F
Discharge Capacity:
10KA(20KA MAX)
Temperature:
-40
⊥
- +
70
⊥
Item Name:
Gas Discharge Protector
Insertion loss:
≒
0.30
Model:
BLQ-GD-3G43MD/FF
V.S.W.R:
≒ 1.20
Class:
Gas Discharge
Impedance:
50 次
Frequency:
DC-3G
Operating Vtg:
75V
Peak Power:
500
W (MAX)
Connector:
4.3-10-F/F
Discharge Capacity:
10KA(20KA MAX)
Temperature:
-40
⊥
- +
70
⊥
Item Name:
Gas Discharge Protector
Insertion loss:
≒
0.25
Model:
BLQ-GD-3GNSMABR
V.S.W.R:
≒ 1.15
Class:
Gas Discharge
Impedance:
50 次
Frequency:
DC-3G
Operating Vtg:
90V/230V
Peak Power:
200
W
Connector:
N/F-SMA/F
Discharge Capacity:
10KA(20KA MAX)
Temperature:
-40
⊥
- +
70
⊥
Item Name:
Gas Discharge Protector
Insertion loss:
≒
0.10
Model:
BLQ-GD-3GDBC
V.S.W.R:
≒ 1.20
Class:
Gas Discharge
Impedance:
50 次
Frequency:
DC-3000MHz
Bulkhead:
Yes
Peak Power:
500
W (MAX)
Connector:
7/16(DIN)-M/F
Discharge Capacity:
20KA
Temperature:
-40
⊥
- +
80
⊥
Item Name:
Gas Discharge Protector
Insertion loss:
≒
0.10
Model:
BLQ-GD-3GDB
V.S.W.R:
≒ 1.20
Class:
Gas Discharge
Impedance:
50 次
Frequency:
DC-3000MHz
Bulkhead:
Yes
Peak Power:
500
W (MAX)
Connector:
7/16(DIN)-M/F
Discharge Capacity:
20KA
Temperature:
-40
⊥
- +
80
⊥
Item Name:
Gas Discharge Protector
Insertion loss:
≒
0.20
Model:
BLQ-GD-2.5GNBZ
V.S.W.R:
≒ 1.15
Class:
Gas Discharge
Impedance:
50 次
Frequency:
DC-2500MHz
Bulkhead:
Yes
Peak Power:
200
W (MAX)
Connector:
N-M/F
Discharge Capacity:
20KA
Temperature:
-40
⊥
- +
85
⊥
Item Name:
Gas Discharge Protector
Insertion loss:
≒
0.20
Model:
BLQ-GD-2.5GTBC
V.S.W.R:
≒ 1.15
Class:
Gas Discharge
Impedance:
50 次
Frequency:
DC-2500MHz
Bulkhead:
Yes
Peak Power:
200
W (MAX)
Connector:
TNC-M/F
Discharge Capacity:
20KA
Temperature:
-40
⊥
- +
85
⊥
Item Name:
Gas Discharge Protector
Insertion loss:
≒
0.20
Model:
BLQ-GD-3GSBC
V.S.W.R:
≒ 1.15
Class:
Gas Discharge
Impedance:
50 次
Frequency:
DC-2500MHz
Bulkhead:
Yes
Peak Power:
200
W (MAX)
Connector:
SMA-M/F
Discharge Capacity:
20KA
Temperature:
-40
⊥
- +
85
⊥
Item Name:
Gas Discharge Protector
Insertion loss:
≒
0.20
Model:
BLQ-GD-2.5GFA
V.S.W.R:
≒ 1.20
Class:
Gas Discharge
Impedance:
75 次
Frequency:
DC-2500MHz
Bulkhead:
Yes
Peak Power:
200W
Connector:
F-M/F
Discharge Capacity:
20KA
Temperature:
-40
⊥
- +
80
⊥
Item Name:
Hybrid Quarter Wave
Insertion loss:
≒
0.20
Model:
BLQ-HGD-722GDB
V.S.W.R:
≒ 1.20
Class:
1/4竹
+Gas Discharge
Impedance:
50 次
Frequency:
698-2200MHz
Bulkhead:
Yes
Discharge Voltage:
90/250/350/600V
Connector:
7/16(DIN)-M/F
Discharge Capacity:
20KA
Temperature:
-40
⊥
- +
80
⊥
Item Name:
Hybrid Quarter Wave
Insertion loss:
≒
0.20
Model:
BLQ-HGD-825GDB
V.S.W.R:
≒ 1.20
Class:
1/4竹
+Gas Discharge
Impedance:
50 次
Frequency:
800-2500MHz
Bulkhead:
Yes
Discharge Voltage:
90/350V
Connector:
7/16(DIN)-F/F
Discharge Capacity:
20KA
Temperature:
-40
⊥
- +
80
⊥
Item Name:
Hybrid Quarter Wave
Insertion loss:
≒
0.20
Model:
BLQ-HGD-727GD
V.S.W.R:
≒ 1.20
Class:
1/4竹
+Gas Discharge
Impedance:
50 次
Frequency:
698-2700MHz
Bulkhead:
Yes
Discharge Voltage:
350V
Connector:
7/16(DIN)-F/F
Discharge Capacity:
30KA
Temperature:
-40
⊥
- +
80
⊥
Item Name:
Gas Discharge Tube
→Vdc(%)
㊣ 20%
Model:
H2R-VXX
I(KA
@8/20米S
5
Class:
Gas Discharge
Tube
I(A
@10/1000米S)
100
Vdc(V@100v/s)
90/150/230/350/600
Cp(pF@1MHz)
≒ 1.5
Gas Discharge
SERIES SURGE PROTECTOR(SURGE ARRESTER)
